M36 LIFTING EYE NUT DIN 582 (DROP-FORGED) A2 STAINLESS STEEL
£12478.87 (exc VAT) per 100
Part No. A58236F
£12478.87 (exc VAT) per 100
| Quantity Breaks | Price per 100 |
|---|---|
| 1 | £12478.87 |
| 2 + | £11854.93 |
| 4 + | £11262.18 |
| 10 + | £10700.63 |
| 20 + | £10039.25 |
Further Information
| Diameter (d) | Pitch | d2 (nom) | d3 (nom) | d4 (nom) | h (nom) | e (nom) |
|---|---|---|---|---|---|---|
| M6 | 1.00 | 16 | 27 | 16 | 31 | 8.0 |
| M8 | 1.25 | 20 | 36 | 20 | 36 | 8.5 |
| M10 | 1.50 | 25 | 45 | 25 | 45 | 10 |
| M12 | 1.75 | 30 | 54 | 30 | 53 | 11 |
| M16 | 2.00 | 35 | 63 | 35 | 62 | 13 |
| M20 | 2.50 | 40 | 72 | 40 | 71 | 16 |
| M24 | 3.00 | 50 | 90 | 50 | 90 | 20 |
| M27 | 3.00 | 65 | 108 | 60 | 109 | 22 |
| M30 | 3.50 | 65 | 108 | 60 | 109 | 25 |
| M36 | 4.00 | 75 | 126 | 70 | 128 | 30 |
